Chapter 23 VLAN Stacking
MES-3728 User’s Guide
200
23.4 Configuring VLAN Stacking
Click Advanced Application > VLAN Stacking to display the screen as shown.
Note: You can not enable VLAN mapping and VLAN stacking at the same time.
Figure 100 Advanced Application > VLAN Stacking
Table 55 802.1Q Frame
DA Destination Address Priority 802.1p Priority
SA Source Address Len/
Etype
Length and type of Ethernet
frame
Tunnel
TPID
Tag Protocol IDentifier added on a
tunnel port
Data Frame data
VID VLAN ID FCS Frame Check Sequence
