Chapter 34 Access Control
MES-3728 User’s Guide
310
Table 105 AAA Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
authenticati
on
authenticationFailure 1.3.6.1.6.3.1.1.5.5 This trap is sent when
authentication fails due to
incorrect user name and/or
password.
AuthenticationFailureEven
tOn
1.3.6.1.4.1.890.1.5.8.45.2
7.2.1
This trap is sent when
authentication fails due to
incorrect user name and/or
password.
RADIUSNotReachableEve
ntOn
1.3.6.1.4.1.890.1.5.8.45.2
7.2.1
This trap is sent when there is
no response message from
the RADIUS server.
RADIUSNotReachableEve
ntClear
1.3.6.1.4.1.890.1.5.8.45.2
7.2.2
This trap is sent when the
RADIUS server can be
reached.
accounting RADIUSNotReachableEve
ntOn
1.3.6.1.4.1.890.1.5.8.45.2
7.2.1
This trap is sent when there is
no response message from
the RADIUS accounting
server.
RADIUSNotReachableEve
ntClear
1.3.6.1.4.1.890.1.5.8.45.2
7.2.2
This trap is sent when the
RADIUS accounting server
can be reached.
Table 106 SNMP IP Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
ping pingProbeFailed 1.3.6.1.2.1.80.0.
1
This trap is sent when a single ping probe
fails.
pingTestFailed 1.3.6.1.2.1.80.0.
2
This trap is sent when a ping test
(consisting of a series of ping probes)
fails.
pingTestCompleted 1.3.6.1.2.1.80.0.
3
This trap is sent when a ping test is
completed.
traceroute traceRoutePathChange 1.3.6.1.2.1.81.0.
1
This trap is sent when a path to a target
changes.
traceRouteTestFailed 1.3.6.1.2.1.81.0.
2
This trap is sent when a traceroute test
fails.
traceRouteTestCompleted 1.3.6.1.2.1.81.0.
3
This trap is sent when a traceroute test is
completed.
