Chapter 6. Browser / Telnet Operation

101

Ratio Use the drop-down list to adjust the icon size of the

receivers / transmitters.

Click and type keywords to filter/search for receivers /

transmitters.

Click this icon to show individual receivers.

Click this icon to show only Video Wall receivers.

Click this icon to show only Receiver Group receivers.

Access Mode Click a device and use the drop-down box to set the

access mode: Occupy, View Only, or Exclusive.

Auto Apply Checking this box allows you to drag and drop devices

and apply the connection immediately without having to

click the Apply button.

Apply Click Apply to connect the devices.

Cancel Click Cancel to exit without connecting.
