Aten RCMDVI40BT [241/297] Edid command
![Aten RCMDVI40BT [241/297] Edid command](/views2/1977522/page241/bgf1.png)
Chapter 14. CLI Commands
225
EDID Command
Extended Display Identification Data (EDID) is a data that contains a display's
basic information and is used to communicate with the video source. The EDID
commands allow you to change the EDID setting of a transmitter. For more
information on configuring EDID settings, see Properties, page 60.
The formula for the EDID command is as follows:
Command + Address + Number + Control + [Enter]
1. For example, if you want to configure device (192.168.0.3) to use the
remix EDID mode, type the following:
edid a192.168.0.3 remix [Enter]
The following tables show the possible values for the EDID commands:
Command Description
edid EDID command
Address Description
a Address command
Number Description
xx Address number
xx: receiver ID or IP address
Control Description
auto Checks the EDID of all connected
displays and the ATEN default EDID to
use the best common resolution for all
displays.
remix Manually checks the EDID of all
connected displays and the ATEN default
EDID to use the best common resolution
for all displays (see EDID Mode,
page 76).
default Implements ATEN’s default EDID.
(default)
manual Manually set the EDID configuration from
the receiver’s OSD (see EDID Mode,
page 76).
