Aten RCMDVI40BT [157/297] Adding users

Chapter 7. System Status

141

Users

The KVM over IP Matrix Manager supports three types of accounts, shown in

the table below:

Adding Users

1. Click on the menu bar.

2. Select Add New User. This window opens:

User Type Role

Administrator Access, push/pull and management of the KVM over IP

Matrix Manager, including configuration and setting up of

devices. Manage Users, Groups, Transmitters, Receivers,

Profiles and Video Walls. Configure personal working

environments.

Super User Access and push/pull receivers, transmitters and Profiles

they have been given permission for.

User Access receivers to connect to transmitters they have been

given permission for.
