Aten RCMDVI40BT [240/297] The control command string can be skipped and lock will be used by default

RCM KVM over IP Transmitter User Manual

224

The following table lists the available Profile commands:

Note: 1. Each command string can be separated with a space.

2. The Control command string can be skipped and lock will be used by

default.

3. For functional lock and release commands, make sure the Lock OSD

when connecting option is checked during Create Profile. Refer to

Lock OSD, page 150 for more information.

Command Profile Num1 Control Description

profile f xx lock Connect profile xx, lock

OSD access

xx:1~99

profile f xx release Connect profile xx, allow

OSD access

xx:1~99

profile f xx back Disconnect profile xx

and return receiver to

OSD menu

xx: 1~99
