Appendix
251
Specifications
RCMDVI00AT / RCMDVI40AT
Function RCMDVI00AT RCMDVI40AT
Connectors Console
Ports
Keyboard 1 x USB Type-A Female (White)
Video 1 x DVI-I Female
(White)
2 x DVI-I Female
(White)
Mouse 1 x USB Type-A Female (White)
Speaker 1 x Mini Stereo Jack (Green)
Mic. 1 x Mini Stereo Jack (Pink)
RS-232 1 x DB-9 Male (Black)
KVM
Ports
KB / Mouse 1 x USB Type-B Female (White)
Speaker 1 x Mini Stereo Jack (Green)
Mic. 1 x Mini Stereo Jack (Pink)
Video 1 x DVI-I Female
(White)
2 x DVI-I Female
(White)
RS-232 1 x DB-9 Female (Black)
Power 2 x DC Jack (Black)
LAN Ports 1 x RJ-45 (Black)
1 x SFP Slot
Internet Port 1 x RJ-45 (Black)
Switches Mode Selection 1 x Slide Switch (Auto, RS-232 Config/Access
Control, Local)
Reset 1 x Semi-recessed Pushbutton
LEDs Link 1 (10: Orange / 100: Orange & Green / 1000:
Green)
Power 1 x Blue
Local 1 x Green
Remote 1 x Green
Emulation Keyboard / Mouse USB
Power Consumption DC12V:12W:60BTU DC12V:18.36W:90
BTU
Video Resolution Up to 1920 x 1200 @ 60Hz
Environment Operating Temp. 0 – 50 ºC
Storage Temp. -20 – 60 ºC
Humidity 0 – 95% RH, Non-condensing
