Aten RCMDVI40BT [44/297] Attaching the bracket

RCM KVM over IP Transmitter User Manual

Attaching the Bracket

Follow the steps below to attach the mounting bracket to the unit, exemplified

using KE6940T:

1. Unscrew the screws from the side shown in the diagram below:

2. Use the screws from step 1 to screw the mounting bracket to the bottom of

the Transmitter as shown below:
