Chapter 14. CLI Commands
233
The following table lists the available List commands:
Note: 1. Each command string can be separated with a space.
2. Skip the Output or Input and Number command strings to view the
local receiver.
Control Description
channel Lists information about the available
channel(s)
profile Lists information about the available
profile and TV wall connections
rx Lists information about the receiver
login Lists information about users logged
into to the OSD menu
connection Lists information about a transmitters
current connections
Comman
d
Output Input Number Control Description
list o xx login List output xx user
logged into OSD.
list o xx rx List output xx receiver
information
list i xx connection List input xx transmitter
information
list channel List all available
channel information
list profile List all available profile
information
list rx List information about
all receivers
list login List information about
all OSD logins
list connection List information about
all connections
