RCM KVM over IP Transmitter User Manual
56
OSD Hotkeys
The OSD hotkeys navigate the receiver’s OSD screens. The hotkeys work after
logging in from the System Login screen (see page 73) but not the OSD
Configuration screen. Pressing a hotkey will immediately take you to the
corresponding OSD screen.
Users can also use the [Page Up] and [Page Down] keys to jump to the previous
and next configuration pages.
Non-OSD Hotkeys
The following are the hotkeys that can be used without entering the OSD
screen:
Reverting to Previous
Users can use the [Alt] + [K] hotkey to switch back to the transmitter channel
previously accessed.
Hotkey Mode
The Hotkey Mode allows users to quickly switch from one transmitter to
another. Either press [Num Lock] + [-] or [Ctrl] + [F12] to enter Hotkey Mode.
Once in Hotkey Mode, you can use the [Next Arrow] and [Previous Arrow]
keys to quickly switch between different transmitters. You can also press a
[Number Key] + [S] / [O] / [E] / [V] to access a transmitter based on its order
number in Favorites (see page 75) by Share / Occupy / Exclusive / View Only
mode.
Hotkey OSD Screen Page
[F1] Connections Page 1 in List Mode 74
[F2] Connections Page 1 in Array Mode 77
[F3] Profile Page 1 78
[F5] Push Content Page 1 79
[F6] Pull Content Page 1 81
[F7] Receiver > Properties 60
[F8] User Preferences 72
[F9] OSD Login Screen
(logs user off)
73
