Aten RCMDVI40BT [283/297] Default password pins

Appendix

267

Default Password Pins

The Default Password pins for different models are shown below.

 RCMDVI00AT / RCMDVI00BT / RCMDVI50T

Note: The unit used in the diagram below is RCMDVI00AT, the default

password pin location for the RCMDVI00BT / RCMDVI50T is

identical.

 RCMDVI40AT / RCMDVI40BT

Note: The unit used in the diagram below is RCMDVI40AT, the default

password pin location for the RCMDVI40BT is identical.
