Aten RCMDVI40BT [165/297] Adding a profile

Chapter 7. System Status

149

Adding a Profile

Creating a Profile allows you to quickly connect single or multiple receiver to

transmitter connections.

1. On the Profile page click and then select Create Profile. The Create

Profile window appears:

Item Description

Name Enter a name for the Profile.

Description Enter a description for the Profile.

Permissions Click Select and check the box of the users / groups you

want to allow to connect this Profile. When the user logs

into a receiver, the profile will appear listed in the OSD

menu on the Profile page (see page 78), allowing them to

connect it.
