RCM KVM over IP Transmitter User Manual
158
Connection Redundancy
You can set up priority connection for receivers. Where a transmitter fails, this
function allows the receiver to connect to the transmitter of the highest priority
that is available.
Follow the steps below to set up the priority list.
1. Click Enable to enable this function.
2. Click Edit. A window will pop-up to allow editing.
CLI Mode CLI Mode Login Use the radio button to Enable or Disable
command line interface logins to the RCM/KE
Manager.
Warning: If Disable CLI Mode Login is selected,
anybody can login via Telnet with administrator
privileges without needing to authenticate,
allowing control of the entire installation. For
installations requiring a high level of security, it’s
recommended that Enable CLI Mode Login be
applied.
Receiver
Login
Settings
Anonymous Login Use this to anonymously log in a user at select
receivers. This option allows users to access the
receiver and connect to transmitters without login.
Click Device List to display the list and check the
box next to the receiver(s) to enable the
Anonymous Login feature.
Anonymous Login
User
When Anonymous Login (above) is enabled for
receivers, select a user from the drop-down menu
to use as the default account for anonymous login
to the receiver.
EDID Mode EDID Mode Use this drop-down menu to set the default EDID
mode for all transmitters. To set a different EDID
mode for each transmitter, use the drop-down
menu to select Customized and then click Edit. A
transmitter list will appear with drop-down menus
to configure each device’s EDID mode.
Connection Redundancy Use this drop-down menu to set connection
redundancy function. You can set up priority
connection with this function.
Please refer to Connection Redundancy on
page 158.
Save Click to save the changes.
Cancel Click to cancel the changes.
