Enter the required information in the fields provided. A description of each
is given in the table below:
Field Description
Username From 1 to 32 characters are allowed depending on the Account
Policy settings.
Local User Check the Local User box if the account is for logging in to the
KVM over IP Matrix Manager or a receiver.
Uncheck the Local User box if the account is authenticated with
a 3rd-party service, such as RADIUS, LDAP/AD, or TACACS+.
See ANMS, page 162 for details.
Password From 6 to 32 characters are allowed depending on the Account
Policy settings.
Confirm Password To be sure there is no mistake in the password, you are asked
to enter it again. The two entries must match.
Description Additional information about the user that you may wish to
include.
Type There are three account categories: Administrator, Super User
and User.
The Administrators have full access to make changes within
the KVM over IP Matrix Manager, which includes adding and
removing transmitters, receivers, accounts, preferences, and
configuration settings.
The Super Users have access to the receiver’s OSD menu
and can connect channels and Profiles.
The Users can log in to Receivers to connect channels.
Status Status allows you to control the user’s account and access, as
follows:
Active provides the user with access and permissions as
granted.
Disable lets you suspend a user’s account without actually
deleting it, so that it can be easily reinstated in the future.
OSD Language Click the drop-down menu to select the language you want to
use during OSD sessions for this user. Options are: Chinese
(Traditional), Simplified Chinese, Japanese, German, Korean,
Russian, French, Spanish, and Portuguese.
Toolbar Hotkey Select the hotkey combination to call the Tool Bar function for
this user. The Tool Bar is used when accessing the computer
from the transmitter or receiver side.
Logout Timeout If there is no user input for the amount of time set with this
function, the user is automatically logged out. A login is
necessary before the KVM over IP Matrix Manager can be
accessed again. The default is 30 minutes.
Screen Blanker Sets how many minutes the device waits when a session is idle
before turning off the display.
