Chapter 14. CLI Commands
221
Mute Command
The Mute command allows you to enable or disable the audio.
The formula for the Mute command is as follows:
Command + Output + Num1 + Control + [Enter]
1. For example, to turn mute off (audio on) for the receiver, type the
following:
mute off [Enter]
2. For example, to turn mute on for receiver (192.168.0.11), type the
following:
mute o192.168.0.11 on [Enter]
3. For example, to turn mute off for receiver (192.168.0.18), type the
following:
mute o192.168.0.18 off [Enter]
The following tables show the possible values for the Mute commands:
The following table lists the available Mute commands:
Command Description
mute Mute command
Output Description
o Output port command
Num1 Description
xx Output number
xx: receiver ID or IP address
Control Description
on Mute on; audio disabled
off Mute off; audio enabled (default)
Command Output Num1 Control Description
mute o xx on Turn mute on for output xx
xx: receiver ID
mute o xx off Turn mute off for output xx
xx: receiver ID
