Chapter 14. CLI Commands
227
Reset Command
The Reset command allows you to reset a device back to the default factory
settings. Reset includes resetting the devices IP address.
Note: The Reset command resets everything but the login information to the
factory default settings. To reset the login information, refer to Reset All
Information on page 266.
The formula for the Reset command is as follows:
Command + Address + Number + [Enter]
1. For example, to reset device (192.168.0.95), type the following:
reset a192.168.0.95 [Enter]
2. For example, to reset the receiver, type the following:
reset [Enter]
The following tables show the possible values for the Reset command:
The following table lists the available Reset commands:
Note: 1. Each command string can be separated with a space.
2. Skip the Address and Number command strings to reset the local
receiver.
Command Description
reset Reset command
Address Description
a Address command
Number Description
xx Address number
xx: receiver ID or IP address
Command Address Num Enter Description
reset a xx [Enter] Reset address xx back to the
factory default settings
xx: Device ID or IP Address
reset [Enter] Resets the receiver settings
