Chapter 3. API Functions
53
Get Remote Session Info
Kill Sessions by User Account
Kill Remote Port Sessions
Sets Denied Access Prompt Message
Error Description Search
For a complete list of the RCM API functions, please contact your local dealer.
Function Description Example
GetSessionByPort(<S
ID>,1,lpBuf,<lpBuf
size>)
Gets the session list information
currently accessing the RCM
device.
GetSessionByPort(4,
1,lpBuf,1024*64)
Function Description Example
KillSessionByName(<
SID>,<username>,<u
sername size>)
Terminates sessions currently
accessed by the specified user.
KillSessionByName(4
,nicholas,8*2)
Function Description Example
KillSessionByPort(<SI
D>,1,<port list>,<port
list length>)
Terminates all sessions currently
accessing the remote port.
KillSessionByPort(4,1
,”\x01”,1)
Function Description Example
SetMessageByPort(<
SID>,1,<prompt
message, max. 30
characters>,<messag
e length>)
Sets a prompt message for
notifying users without access
rights to the remote port.
SetMessageByPort(4,
1,access denied,13*2)
Function Description Example
GetErrorDescription(<
error code>)
Searches for error description by
a specified returned error value.
GetErrorDescription(-
9)
