Aten RCMDVI40BT [78/297] System

RCM KVM over IP Transmitter User Manual

System

The System tab allows you to configure the receiver’s general settings:

After entering the information, click Save.

Item Description

Device

Information

Enter the Name, and Description of the receiver. It also

displays the IP Address, MAC Address, F/W Version, and Serial

Number of the receiver.

Reboot Check the box and click Reboot to reset the receiver’s settings

back to the factory default. All custom settings (except for login

account settings) will be lost.

Receiver

Password

Change

Check Enable to require a password for access to the

receiver’s OSD configuration screen. Enter the Old Password,

enter a New Password, and confirm the new password in the

Confirm Password box.
