Chapter 2. Hardware Setup

RCMDVI40AT Point-to-Point Installation 1 of 2

Note: The diagram above shows the RCMDVI40AT setup with a KE6940AR.

The RCMDVI00AT-KE6900AR installation is the same except with

one less DVI monitor.

KE6940AR (Rear)

RCMDVI40AT (Rear)

Cat 5e/6 cable

Optical Fiber Cable

Cat 5e/6 cable

Optical Fiber Cable

DC 12V

DC 5V

Serial

Device

Serial

Device

Office LAN

DC 12V

DC 5V
