Aten RCMDVI40BT [242/297] The following table lists the available edid commands

RCM KVM over IP Transmitter User Manual

226

The following table lists the available EDID commands:

Command Address Number Control Enter Description

edid a xx auto [Enter] Set EDID of address xx to auto.

xx: Device ID or IP Address

edid a xx remix [Enter] Set EDID of address xx to remix.

xx: Device ID or IP Address

edid a xx default [Enter] Set EDID of address xx to

default.

xx: Device ID or IP Address

edid a xx manual [Enter] Set EDID of address xx to

manual.

xx: Device ID or IP Address

Содержание

Rcmdvi00at rcmdvi40at kvm over ip extender cckm software user manual 1
Compliance statements 2
Online registration 4
Telephone support 4
User information 4
User notice 4
For information about all aten products and how they can help you connect without limits visit aten on the web or contact an aten authorized reseller visit aten on the web for a list of locations and telephone numbers 5
Product information 5
Package contents 6
Rcmdvi00at rcmdvi40at 6
Rcmdvi00bt rcmdvi40bt rcmdvi50t 6
Chapter 1 7
Chapter 2 7
Contents 7
Hardware setup 7
Introduction 7
Api functions 8
Chapter 3 8
Chapter 4 8
Osd operation 8
Browser telnet operation 9
Chapter 5 9
Chapter 6 9
Chapter 7 9
Software installation 9
System status 9
Chapter 8 10
System settings 10
Chapter 10 11
Chapter 11 11
Chapter 12 11
Chapter 13 11
Chapter 9 11
Connections 11
Firmware upgrade utility 11
Remote viewer 11
Scheduled profile 11
Sessions 11
Appendix 12
Chapter 14 12
Cli commands 12
About this manual 14
Conventions 16
This manual uses the following conventions 16
Chapter 1 17
Chapter 1 introduction 17
Introduction 17
Overview 17
In addition they support fiber channel over ethernet via sfp fiber modules which connect to a network switch at speeds up to 1 gbps the rcm transmitters can connect to ke receivers unit to unit or over a tcp ip network via gigabit ethernet or the sfp ports connecting via both methods allows network failover 18
Models 18
Rcm kvm over ip transmitter user manual 18
Rcm kvm over ip transmitters allow flexible setup as they can be integrated to pc to console connections in several ways one to one extender mode one to many splitter mode many to one switch mode or many to many matrix mode 18
Rcm transmitters have rs 232 ports to connect to a serial terminal for configuration or serial devices such as touch screens and barcode scanners they can connect to an office lan to support the control center video session recorder ccvsr software and winclient j avaclient the ccvsr records all operations made on the pcs and or workstations accessed through rcm transmitters every operation and change is recorded and saved to a secure video file for purposes such as security reference and troubleshooting by using winclient javaclient you are provided with console access from a separate location over tcp ip 18
Refer to the table below for the variations in interfaces functions and features 18
The kvm over ip matrix manager cckm allows you to define the aforementioned matrix connections and manage rcm ke transmitters and ke receivers with features such as auto detection username password authentication switching and sharing of connections scheduling permissions and more whether you re extending computer access for monitoring broadcasting editing or workstation setup the kvm over ip matrix system gives you the flexibility and control to manage one or hundreds of extended connections for more detailed feature list refer to features on page 4 18
The rcm transmitters support on screen display osd configurations from the connected ke receivers to configure both receivers and transmitters for easy setup and operation 18
Comparison table 19
Note the sfp module is sold separately you can choose the 2a 136g a multi mode sfp module that provides 1 gbe connectivity up to 550 meters or the 2a 137g a single mode sfp module that provides 1 gbe connectivity up to 10 kilometers visit aten s website or contact your aten dealer for more information 19
Exclusive rcm functionalities 20
Features 20
Hardware 20
Management 21
Security 21
Advanced feature 22
Advanced features9 22
Virtual media 22
Rcm kvm over ip transmitter user manual 24
Resolutions 24
Supported video resolutions 24
Cables 25
Computers 25
Console 25
Requirements 25
Minimum hardware software requirements 26
4 5 6 2 27
Components 27
Rcmdvi00at front view 27
Rcmdvi00at rear view 28
4 5 6 2 30
Rcmdvi40at front view 30
Rcmdvi40at rear view 31
5 6 7 3 33
Rcmdvi00bt front view 33
Rcmdvi00bt rear view 34
5 6 7 3 36
Rcmdvi40bt front view 36
Rcmdvi40bt rear view 37
5 6 7 3 39
Rcmdvi50t front view 39
Rcmdvi50t rear view 40
This page intentionally left blank 42
Chapter 2 43
Chapter 2 hardware setup 43
Hardware setup 43
Mounting 43
Attaching the bracket 44
Rack mount 45
Wall mount 46
Rcmdvi00at rcmdvi40at point to point installation 47
Rcmdvi40at point to point installation 1 of 2 49
Rcmdvi40at front 50
Rcmdvi40at point to point installation 2 of 2 50
Rcmdvi00at rcmdvi40at lan installation 51
Rcmdvi00at rcmdvi40at network installation diagram 1 of 2 52
Tcp ip lan 52
Rcmdvi00at rcmdvi40at network installation diagram 2 of 2 53
Rcmdvi40at front 53
Usb dvi d kvm cable 53
Rcmdvi00bt rcmdvi40bt rcmdvi50t point to point installation 54
Rcmdvi40bt point to point installation 1 of 2 56
Chapter 2 hardware setup 57
Note the serial port on the transmitter shown above connects to the computer the serial port on the receiver not shown connects to a serial device optional 57
Rcmdvi40bt point to point installation 2 of 2 57
Rcmdvi00bt rcmdvi40bt rcmdvi50t lan installation 58
Ke6910r rear 60
Rcm kvm over ip transmitter user manual 60
Rcmdvi00bt rcmdvi40bt rcmdvi50t network installation diagram 1 of 2 60
Rcmdvi40bt rear 60
Tcp ip lan 60
Rcmdvi00bt rcmdvi40bt rcmdvi50t network installation diagram 2 of 2 61
Rcmdvi40bt front 61
Usb dvi d kvm cable 61
Network configuration 62
Default ip addresses 63
Exit osd 63
Rcm i o ports 64
The following table provides the port values used by rcm ke series devices 64
Api functions 65
Chapter 3 65
Chapter 3 api functions 65
Overview 65
Starting an api session 65
Access management 66
Checking access control box pushbutton 66
Local console access 66
Remote port access 66
Remote monitoring 67
The following sequence of functions are used for capturing the image of the rcm device for remote monitoring 67
Type the following to check if there are any new updates changes to the image since the last time interval 67
Type the following to get the buffer size of the image captured 67
Type the following to get the data of the image captured 67
Type the following to set the parameters for capturing images from the rcm device including its quality width height and time interval 67
Ocr functions 68
Other api functions 68
Read text 68
Remote access 68
Sample image compare 68
Set mouse mode 68
Error description search 69
For a complete list of the rcm api functions please contact your local dealer 69
Get remote session info 69
Kill remote port sessions 69
Kill sessions by user account 69
Sets denied access prompt message 69
This page intentionally left blank 70
Chapter 4 71
Invoking the osd 71
Osd operation 71
Overview 71
Touch screen calibration 71
Hotkey mode 72
Non osd hotkeys 72
Once in hotkey mode you can use the next arrow and previous arrow keys to quickly switch between different transmitters you can also press a number key s o e v to access a transmitter based on its order number in favorites see page 75 by share occupy exclusive view only mode 72
Osd hotkeys 72
Reverting to previous 72
The following are the hotkeys that can be used without entering the osd screen 72
The hotkey mode allows users to quickly switch from one transmitter to another either press num lock or ctrl f12 to enter hotkey mode 72
The osd hotkeys navigate the receiver s osd screens the hotkeys work after logging in from the system login screen see page 73 but not the osd configuration screen pressing a hotkey will immediately take you to the corresponding osd screen 72
Users can also use the page up and page down keys to jump to the previous and next configuration pages 72
Users can use the alt k hotkey to switch back to the transmitter channel previously accessed 72
Osd interface 73
Click ok and change the password in the dialog box shown below 74
Enter the password and confirm it in the next field the password must be different from your original password 74
First time login 74
For security purposes the system will prompt you to change the login password immediately as shown below 74
If you are the administrator and are logging in for the first time receiver or user preference radio button use the default password password 74
After entering the information click save 75
Network 75
Receiver configuration 75
Select the receiver radio button and click configure to login the network tab appears 75
The network tab allows you to configure the receiver s ip address settings 75
Properties 76
The properties tab allows you to configure the receiver s settings 76
After entering the information click save 77
After entering the information click save 78
System 78
The system tab allows you to configure the receiver s general settings 78
After entering the information click save 79
Network 79
The network tab allows you to configure the transmitter s ip address settings 79
Transmitter configuration 79
When you select the transmitter radio button and click configure to login the network tab appears 79
Properties 80
The properties tab allows you to configure the transmitter s extender settings 80
After entering the information click save 82
After entering the information click save 83
System 83
The system tab allows you to configure the transmitter s general settings 83
Internet port 84
User preferences 88
When you have made your choices click save 88
When you select the user preferences radio button and click configure to login the configuration screen appears 88
Osd matrix mode 89
Connections page 90
List mode 90
The connection page components are described in the table below 90
Array mode 93
In array mode the screen is divided into a grid of panels with each panel showing the video display of a particular channel right click a panel and select a mode to connect e exclusive o occupy s share v view only x exit while video is displayed when the mouse cursor hovers over it any audio sent from the transmitter will be heard by the receiver 93
Click the profile page tab and the following screen appears 94
Profile page 94
The profile page components are described in the table below 94
Push content 95
Push content allows you to push the receiver s channel connection to another receiver s console allowing both to access the computer select the push content tab and the following screen appears 95
The push content page components are described in the table below 95
Pull content 97
Pull content allows you to pull a receiver s computer connection to the local receiver s console allowing both to access to the computer click the pull content tab and the following screen appears 97
The pull content page components are described in the table below 97
This page intentionally left blank 98
Chapter 5 99
Download 99
Overview 99
Software installation 99
Installing the kvm over ip matrix manager 101
Upgrading license 104
Linux installation 105
This page intentionally left blank 108
Browser telnet operation 109
Chapter 6 109
Logging in 109
Overview 109
After you have successfully logged in the web browser s main page appears 111
The kvm over ip matrix manager main page 111
The web components are described in the table below 111
Web components 111
Interactive display panel 112
The functions associated with each of the icons on the main interactive display panel are explained in the table below 112
Check the boxes under transmitter receiver to select the devices you want to add then click next 113
Connect all transmitters and receivers to the lan 113
Installation wizard 113
On the cckm main page click the install wizard icon page 95 113
Under assign ip address select an option to configure the network settings then click next 113
Use the install wizard to add transmitters and receivers to the cckm the wizard locates devices on the network and walks you through adding them to add devices do the following 113
When the installation wizard appears select options to locate devices 113
At the bottom of the kvm over ip matrix manager main page is the instant link bar in this section you can quickly connect receivers to transmitters 116
Instant link 116
The top panel provides the receiver list and the bottom panel provides the transmitter list to create a connection click a receiver in the top panel and use the drop down menu to select a transmitter as shown in the image below or drag and drop transmitters from the bottom panel to receivers in the top panel configure as many receiver to transmitter connections as needed and then click apply 116
Rs 232 telnet 118
Telnet 118
Rs 232 119
Configuration menu 120
Chapter 7 123
Overview 123
System status 123
System status 124
The system status panel has five sections that provide information and a link to each settings page each settings page can be accessed by clicking within the section transmitter receiver users profile or log each section is explained in the table below and the settings on the pages that follow 124
Transmitter 126
Transmitter configuration 128
When the kvm over ip matrix manager discovers transmitters on the network they appear on the transmitter settings page double click a transmitter to configure its settings 128
Creating a virtual transmitter allows you to create one connection that sources media kvm audio usb serial from different transmitters virtual transmitters appear on the transmitter settings page with virtual tx in the top right corner simply select an online transmitter for each media source dual display transmitters can be added as two separate virtual transmitters 140
To create a virtual transmitter in transmitter settings click and then select create virtual tx 140
Virtual transmitter 140
Transmitter group 142
Transmitter permissions 143
Receiver 145
Receiver configuration 147
Creating a receiver group allows you to connect the video from multiple transmitters to multiple receiver displays to use this feature connect a transmitter group page 126 to a receiver group see instant link page 100 receiver groups appear at the bottom of the receiver settings page 151
Fill in the appropriate information and then double click or drag and drop receivers to add or remove them in the top panel the receivers in the top panel will be used to view the video from the transmitter group to connect a transmitter group to a receiver group see instant lin 151
Note you can create up to 4 receiver groups 151
Page 10 151
Receiver group 151
To create a receiver group in receiver settings click and then select create rx group 151
Video wall 152
Receiver permissions 155
Receiver permissions sets which users and groups can access a receiver select a device under the receiver list and then click under operation to grant a user or group permission to access the device this will allow the user to log into the receiver s osd menu to access the connections tab 155
To set receiver permissions in receiver settings click 155
Account 156
Click user s in the system status panel to open the settings the account page allows you to add delete and configure users and groups instructions for adding users and groups is provide on page 141 156
Depending on the item selected either users or groups are listed on the page 156
The sort order of the information displayed can be changed by clicking the column headings 156
The users and group buttons appear at the top of the page 156
Three icons in the right corner are used to add users groups and set permissions as explained in the sections that follow 156
Adding users 157
Click on the menu bar 157
Select add new user this window opens 157
The kvm over ip matrix manager supports three types of accounts shown in the table below 157
Enter the required information in the fields provided a description of each is given in the table below 158
Click ok 159
Deleting users 159
In the edit user page that comes up make your changes then click apply 159
In the main panel check the box next to the user s name 159
In the main panel double click the user s name 159
Modifying users 159
The columns show the username user level status osd language description and group 159
The new user appears on the main panel 159
When the operation succeeded message appears click ok 159
When your selections have been made click apply 159
Adding groups 160
Groups 160
Deleting groups 161
Modifying groups 161
Assigning device permissions 162
Click on the menu bar the set user permissions window opens 162
Permissions 162
To set the permissions select a user or group then a device and select the access type under each column so that it turns green make your permission settings for each user or group on each device according to the information provided below 162
You can assign transmitter receiver and profile permissions for users and groups from the account page 162
In the confirmation popup that appears click ok 163
When you have finished making your choices click apply 163
Profile 164
Adding a profile 165
Creating a profile allows you to quickly connect single or multiple receiver to transmitter connections 165
On the profile page click and then select create profile the create profile window appears 165
After filling in the information click a receiver select select tx and use the drop down menu select a transmitter or use transmitter list at the bottom of the page to drag and drop transmitters to receivers to create the connection 166
Adding a schedule 167
After the schedule is configured click save 168
This page intentionally left blank 170
Chapter 8 171
General 171
Overview 171
System settings 171
Click edit a window will pop up to allow editing 174
Click enable to enable this function 174
Connection redundancy 174
Follow the steps below to set up the priority list 174
You can set up priority connection for receivers where a transmitter fails this function allows the receiver to connect to the transmitter of the highest priority that is available 174
Login access priority 177
Event destination 178
Authentication authorization 180
Ldap ad settings 181
On the ldap ad server users can be authenticated with any of the following methods 181
To allow authentication and authorization for the rcm ke manager via ldap ad refer to the information in the table below 181
With ms active directory schema 181
Fw upgrade 184
Firmware upgrade recovery 185
Redundancy 186
Backup restore 188
The backup restore tab is divided into three panels backup restore and export device list 188
The operations to perform backup restore procedures are described in the table below and in the section that follows 188
Backup 189
Restore 189
Certificates 190
Private certificate 190
Certificate signing request 191
Sessions 193
This page intentionally left blank 194
Chapter 9 195
Connections 195
Overview 195
Connections 196
Over the connection diagram 196
When receivers connect to transmitters they appears in the connections panel there are two columns each lists either transmitters or receivers the columns can be swapped by clicking the tx rx or rx tx button devices in the left column can be clicked to display their connection to devices shown in the right column connections shown in the right column can be disconnected by clicking the 196
Based on the different access types users attempting to connect to device ports that are already being accessed by another user may or may not be able to connect see the table below for scenarios where users are granted o or denied access x 197
This page intentionally left blank 198
Chapter 10 199
Overview 199
Scheduled profile 199
The scheduled profile panel is found on the kvm over ip matrix manager main page just below connections scheduled profiles displays connection profiles that have been scheduled click go to schedule to edit and create profile schedules page 151 to create profiles see page 149 199
This page intentionally left blank 200
Chapter 11 201
Overview 201
Sessions 201
The sessions panel is found at the bottom of the kvm over ip matrix manager main page just below scheduled profile sessions displays information about users logged into devices and the kvm over ip matrix manager web gui click go to sessions to view the settings page see page 177 201
This page intentionally left blank 202
Chapter 12 203
Introduction 203
Remote viewer 203
Windows and java client viewer web access 204
Download 206
The windows java client ap 206
Connected a login window appears 207
Double click the unit when the uni 207
For the first time running the ap right click the windows java client ap and click run as administrator to start 207
Starting up 207
The client connection screen is shown below and each components are described in the table windows client will be the example shown here 207
The control panel 209
Control panel functions 210
The control panel functions are described in the table below 210
Macros 212
An explanation of the hotkey actions is given in the table below 213
To reset all the hotkeys to their default values click reset 213
The adjustment options are as follows 214
The video settings dialog box allows you to adjust the placement and picture quality of the remote screen display on your monitor 214
Video settings 214
For gamma level there are ten preset and four user defined levels to choose from click the drop down menu and choose the most suitable one 215
For greater control and if it is necessary to correct the gamma level for the remote video display use the gamma function of the advanced video settings by clicking the advanced button 215
Gamma adjustment 215
The additional options in the advanced screen are as follows 215
Click cancel to abandon your changes and close the dialog box 216
Click ok to save your changes and close the dialog box 216
Note for best results change the gamma while viewing a remote computer 216
Virtual media 217
The on screen keyboard 221
Mouse dynasync mode 222
Mouse pointer type 222
Clicking the customize control panel icon brings up a dialog box that allows you to configure the items that appear on the control panel as well as its graphical settings 224
Control panel configuration 224
The dialog box is organized into five main sections as described in the table below 224
This page intentionally left blank 226
Chapter 13 227
Firmware upgrade utility 227
Preparation 227
Starting the upgrade 228
Firmware upgrade recovery 230
Upgrade succeeded 230
Chapter 14 231
Cli commands 231
Configuring the serial port 231
Serial control protocol commands 231
Device profile commands 232
Telnet 232
Verification 232
Switch port command 233
The following tables show the possible values for the switch port commands 234
All sets all source streams 235
Chapter 14 cli commands 235
Connect description 235
Logout logout osd 235
Off disconnect 235
On connect 235
Stream description 235
The following table lists the available switch port commands 235
Usb sets the usb source stream 235
Note 1 each command string can be separated with a space 236
Rcm kvm over ip transmitter user manual 236
Receiver 236
Skip the output and num1 command strings to configure the local 236
The mode command string can be skipped and view only will be used by default 236
Command output num1 control enter 237
For example to turn mute off audio on for the receiver type the following 237
For example to turn mute off for receiver 192 68 8 type the following 237
For example to turn mute on for receiver 192 68 1 type the following 237
Mute command 237
Mute o192 68 1 on enter 237
Mute o192 68 8 off enter 237
Mute off enter 237
The following table lists the available mute commands 237
The following tables show the possible values for the mute commands 237
The formula for the mute command is as follows 237
The mute command allows you to enable or disable the audio 237
Command profile num1 control enter 239
For example to connect profile 4 with access to the osd menu type the following 239
For example to connect profile 8 and lock the osd menu type the following 239
For example to disconnect profile 12 and return to the receiver to the osd menu type the following 239
Profile command 239
Profile f12 back enter 239
Profile f4 release enter 239
Profile f8 enter 239
The following tables show the possible values for the profile commands 239
The formula for profile commands is as follows 239
The profile command allows you to connect profiles and video walls 239
For functional lock and release commands make sure the lock osd when connecting option is checked during create profile refer to lock osd page 150 for more information 240
Note 1 each command string can be separated with a space 240
The control command string can be skipped and lock will be used by default 240
The following table lists the available profile commands 240
Command address number control enter 241
Edid a192 68 remix enter 241
Edid command 241
Extended display identification data edid is a data that contains a display s basic information and is used to communicate with the video source the edid commands allow you to change the edid setting of a transmitter for more information on configuring edid settings see properties page 60 241
For example if you want to configure device 192 68 to use the remix edid mode type the following 241
The following tables show the possible values for the edid commands 241
The formula for the edid command is as follows 241
The following table lists the available edid commands 242
Command address number enter 243
For example to reset device 192 68 5 type the following 243
For example to reset the receiver type the following 243
Note 1 each command string can be separated with a space 243
Note the reset command resets everything but the login information to the factory default settings to reset the login information refer to reset all information on page 266 243
Receiver 243
Reset a192 68 5 enter 243
Reset command 243
Reset enter 243
Skip the address and number command strings to reset the local 243
The following table lists the available reset commands 243
The following tables show the possible values for the reset command 243
The formula for the reset command is as follows 243
The reset command allows you to reset a device back to the default factory settings reset includes resetting the devices ip address 243
Baud 19200 enter 244
Baud a192 68 3 38400 none 8 1 enter 244
Command address number baud rate parity data bit stop bit flow control enter 244
For example to set device 192 68 3 with a baud rate of 38400 parity of none data bit of 8 and stop bit of 1 type the following 244
For example to set the local device with a baud rate of 19200 type the following 244
Rs 232 command 244
The following tables show the possible values for the rs 232 command 244
The formula for the rs 232 command is as follows 244
The rs 232 command allows you to set the rs 232 settings for a device 244
The following table lists the available baud rate commands 245
Local device settings 246
Note 1 each command string can be separated with a space 246
Skip the address and number command strings to configure the 246
The baud rate value is required but parity data bit and stop bit can be skipped and their setting will not change 246
Command output number control enter 247
For example to disable the osd for the local receiver type 247
For example to enable the osd for receiver 192 68 1 type 247
Note 1 each command string can be separated with a space 247
Osd command 247
Osd o192 68 1 on enter 247
Osd off enter 247
Receiver 247
Skip the output and number command strings to configure the local 247
The following table lists the available osd commands 247
The following tables show the possible values for the osd command 247
To enable or disable the on screen display osd menu for a receiver use the following command 247
List command 248
Local receiver 249
Note 1 each command string can be separated with a space 249
Skip the output or input and number command strings to view the 249
The following table lists the available list commands 249
Command output input number control enter 250
For example to read all of receiver 192 68 9 device properties type the following 250
For example to read all of the local receiver s properties type the following 250
For example to read all of transmitter 192 68 8 device properties type the following 250
For example to read the basic properties of receiver 192 68 1 type the following 250
For example to read the network properties of transmitter 192 68 1 type the following 250
Read all enter 250
Read command 250
Read i192 68 1 network enter 250
Read i192 68 8 all enter 250
Read o192 68 1 basic enter 250
Read o192 68 9 all enter 250
The following tables show the possible values for the read comman 250
The formula for the read command is as follows 250
The read command allows you to retrieve the properties of a device 250
The following table lists the available read commands 251
Local receiver properties 253
Note 1 each command string can be separated with a space 253
Skip the output or input and number command strings to read the 253
Set command 254
The following table lists the available set commands 256
This page intentionally left blank 262
Appendix 263
General 263
Safety instructions 263
Rack mounting 265
International 266
North america 266
Technical support 266
Rcmdvi00at rcmdvi40at 267
Specifications 267
Rcmdvi00b 269
Rcmdvi40bt 269
Rcmdvi50t 271
Dual rack mount 273
Optional rack mount 273
Screw the mounting brackets to the rack 274
Use the screws in step 2 to install the left and right mounting brackets 274
Single rack mount 277
Screw the mounting brackets to the rack 278
Use the screws in step 2 to install the right and left mounting brackets 278
Ip installer 279
Overview 280
Trusted certificates 280
Examples 281
Importing the files 281
Self signed private certificates 281
Reset all information 282
Default password pins 283
Pin assignments for the transmitter and receiver s rear rs 232 port that is used for connecting to a serial terminal are given in the table below 284
Rs 232 pin assignments 284
Transmitter front rs 232 port pin assignments for the transmitter s front rs 232 port that is used for connecting to a computer for serial control are given in the table below 284
All audio and video multicast ip addresses use the format 230 x y z 285
Example 285
If x is between 0 127 285
Multicast ip address 285
Multicast ip formula 285
Multicasting helps to broadcast audio and video data from a transmitter to multiple receivers over a network to setup up multicasting on a network switch you must know the audio and video multicast ip address which can be found on the rcm ke transmitter to determinate the default multicast ip address set by the rcm ke device use the instructions below the multicast ip addresses can be set manually using telnet 285
Rcm ke multicast rule 285
To calculate the audio and video multicast ip address use the transmitter s ip address to determine x and then use the appropriate table below to calculate the multicast ip address for each data stream audio video 285
Transmitter ip address 172 16 7 46 172 x y z 285
X y z relates to the transmitter s ip address and 230 is always the first octet of a multicast ip address you use the transmitter s ip address to find x and then use it to calculate the audio and video multicast ip address 285
If x is 192 or higher 286
If x is between 128 192 286
Build a network diagram 287
Keys to network performance 287
Choose a high performance switch 289
Considerations 289
Configuring switches and rcm ke devices 291
Recommended network switches 292
Additional mouse synchronization procedures 293
Windows 293
Sun linux 294
Java applet viewer java client ap 295
Virtual media support 295
Winclient activex viewer winclient ap 295
Cckm server ip address setup on windows 296
Limited warranty 297

Aten RCMDVI40BT [242/297] The following table lists the available edid commands

Содержание

Похожие устройства
