Aten RCMDVI40BT [64/297] The following table provides the port values used by rcm ke series devices

RCM KVM over IP Transmitter User Manual

RCM I/O Ports

The following table provides the port values used by RCM/KE series devices.

Device Port Number

KVM over IP Matrix

Manager (TCP)

HTTP 8080

HTTPS 8443

Device TCP 9110

CLI 9111

Redundancy 9120

Database Service 1527

KVM over IP Matrix

Manager (UDP)

Port 9110

Broadcast 9000

RCM/KE TX/RX Device

(TCP)

Manager 9110

Service 9000

Telne t 23

SSH 22

RCM/KE TX Device (TCP) VM 9001

vUSB 9002

Serial 9003

USB Access Mode 9009

KE RX Device (TCP) CLI 9130

RCM/KE KE TX/RX Device

(UDP)

Manager 9110

Service 9000

Array Mode 9120

Video 0xFE00(65024) - 0xFE03(65027)

Audio 0xFE04(65028) - 0xFE05(65029)
