Optional Rack Mount

For convenience and flexibility, three optional rack mount kits are available as

shown in the following table:

*Supports RCMDVI00AT / RCMDVI40AT / RCMDVI00BT /

RCMDVI40BT / RCMDVI50T.

Dual Rack Mount

The 2X-021G Dual Rack Mount Kit installs two RCM units side by side in 1U

of server rack space.

Transmitter Dual Rack Mount

KE8950T is the example used here.

1. Remove four screws from the units and then use the same screws to secure

the units together with the link bracket provided with the kit.

2. Remove the bottom and side screws from each unit.

Mounting Type Model

Dual Rack Mount Kit* 2X-021G

Single Rack Mount Kit* 2X-031G
