Aten RCMDVI40BT [245/297] The following table lists the available baud rate commands
![Aten RCMDVI40BT [245/297] The following table lists the available baud rate commands](/views2/1977522/page245/bgf5.png)
Chapter 14. CLI Commands
229
The following table lists the available Baud Rate commands:
7 Sets the data bit to 7
8 Sets the data bit to 8
Stop Bit Description
1 Sets the stop bit to 1
2 Sets the stop bit to 2
Flow Control Description
None Sets flow control to none
Hardware Sets flow control to hardware
Xon Sets flow control to Xon
Xoff Sets flow control to Xoff
Com
mand
Address
Num
1
Baud
Rate
Parity
Data
Bit
Stop
Bit
Flow
Control
Description
baud a xx 9600 None
Even
Odd
5
6
7
8
1
2
None
Hardware
Xon/Xoff
Set address xx
baud rate to
9600, with
parity/ data bit/
stop bit / flow
control setting
baud a xx 19200 None
Even
Odd
5
6
7
8
1
2
None
Hardware
Xon/Xoff
Set address xx
baud rate to
19200, with
parity/ data bit/
stop bit / flow
control setting
baud a xx 38400 None
Even
Odd
5
6
7
8
1
2
None
Hardware
Xon/Xoff
Set address xx
baud rate to
38400, with
parity/ data bit/
stop bit / flow
control setting
baud a xx 115200 None
Even
Odd
5
6
7
8
1
2
None
Hardware
Xon/Xoff
Set address xx
baud rate to
115200, with
parity/ data bit/
stop bit / flow
control setting
Data Bit Description
