RCM KVM over IP Transmitter User Manual
270
If X is between 128 ~ 192
If X is 192 or higher
Transmitter
IP
X - 128
= A
Video
A + 128
Audio
A + 192
Multicast
Video IP
Address
Multicast
Audio IP
Address
172.168.27.14
(example)
168 - 128
= 40
40 + 128
= 168
40 + 192
= 232
230.168.27.14 230.232.27.14
___ - 128
=
___+ 128
=
___+ 192
=
230.___.___.__ 230.___.___.__
___ - 128
=
___+ 128
=
___+ 192
=
230.___.___.__ 230.___.___.__
___ - 128
=
___+ 128
=
___+ 192
=
230.___.___.__ 230.___.___.__
Transmitter
IP
X - 192
= A
Video
A + 128
Audio
A + 192
Multicast
Video IP
Address
Multicast
Audio IP
Address
172.200.27.14
(example)
200 - 192
= 8
8 + 128
= 136
8 + 192
= 200
230.136.27.14 230.200.27.14
___ - 192
=
___+ 128
=
___+ 192
=
230.___.___.__ 230.___.___.__
___ - 192
=
___+ 128
=
___+ 192
=
230.___.___.__ 230.___.___.__
___ - 192
=
___+ 128
=
___+ 192
=
230.___.___.__ 230.___.___.__
