Chapter 14. CLI Commands
219
The following table lists the available Switch Port commands:
usb Sets the USB source stream
all Sets all source streams
Connect Description
on Connect
off Disconnect
logout Logout OSD
Command Output Num1 Input Num2 Mode Stream
Con-
nect
Description
sw o xx i yy exclusive video
audio
serial
usb
all
on Switch output xx to input
yy with exclusive access
to source(s).
xx: receiver ID
yy: rransmitter ID
sw o xx i yy share video
audio
serial
usb
all
on Switch output xx to input
yy with share access to
stream source(s).
xx: receiver ID
yy: transmitter ID
sw o xx i yy occupy video
audio
serial
usb
all
on Switch output xx to input
yy with occupy access to
stream source(s).
xx: receiver ID
yy: transmitter ID
sw o xx i yy viewonly video
audio
serial
usb
all
on Switch output xx to input
yy with viewonly access
to stream source(s).
xx: receiver ID
yy: transmitter ID
sw o xx off Switch output xx,
disconnect streams,
return to OSD menu.
xx: receiver ID
sw o xx logout Switch output xx,
disconnect streams and
logout from OSD menu.
xx: receiver ID
sw video
audio
serial
usb
all
off Switch receiver
stream(s) to disconnect.
Stream Description
