Chapter 14. CLI Commands
231
OSD Command
To enable or disable the On-Screen Display (OSD) menu for a receiver, use the
following command:
Command + Output + Number + Control + [Enter]
1. For example, to enable the OSD for receiver 192.168.0.51, type:
osd o192.168.0.51 on [Enter]
2. For example, to disable the OSD for the local receiver, type:
osd off [Enter]
The following tables show the possible values for the OSD command:
The following table lists the available OSD commands:
Note: 1. Each command string can be separated with a space.
2. Skip the Output and Number command strings to configure the local
receiver.
Command Description
osd OSD command
Output Description
o Output command
Number Description
xx Output number
xx: receiver ID or IP address
Control Description
on Enable OSD functions
off Disable OSD functions (default)
Comman
d
Output Number Control Enter Description
osd
oxx
on [Enter] Enable OSD functions for
output xx
xx: receiver ID or IP address
osd
oxx
off [Enter] Disable OSD functions for
output xx off (default)
xx: receiver ID or IP address
