RCM KVM over IP Transmitter User Manual
220
Note: 1. Each command string can be separated with a space.
2. The Mode command string can be skipped and view only will be used
by default.
3. Skip the Output and Num1 command strings to configure the local
receiver.
sw off Switch receiver
disconnect streams,
return to OSD menu.
sw i @zz exclusive
share
occupy
viewonly
video
audio
serial
usb
all
on Switch receiver to input
@zz with [mode] access
to stream source(s).
zz: transmitter # by order
listed in the command
line interface.
sw o xx i @zz exclusive video
audio
serial
usb
all
on Switch output xx to input
@zz with [mode] access
to stream source(s).
xx: receiver ID
zz: transmitter # by order
listed in command line
interface.
Command Output Num1 Input Num2 Mode Stream
Con-
nect
Description
