RCM KVM over IP Transmitter User Manual
44
RCMDVI00BT / RCMDVI40BT / RCMDVI50T Network
Installation Diagram 1 of 2
KE6910R (Rear)
RCMDVI40BT (Rear)
TCP/IP
LAN
Cat 5e/6 cable
Optical Fiber Cable
Office LAN
DC 12V
Serial
Device
Cat 5e/6 cable
Optical Fiber Cable
DC 5V
Serial
Device
DC 5V
