Appendix
255
RCMDVI50T
Function RCMDVI50T
Connectors Console
Ports
Keyboard 1 x USB Type-A Female (White)
Video 1 x DVI-I Female (White)
Mouse 1 x USB Type-A Female (White)
Speaker 1 x Mini Stereo Jack (Green)
Mic. 1 x Mini Stereo Jack (Pink)
RS-232 1 x DB-9 Male (Black)
KVM
Ports
KB / Mouse 1 x USB Type-B Female (White)
Speaker 1 x Mini Stereo Jack (Green)
Mic. 1 x Mini Stereo Jack (Pink)
Video 1 x DVI-I Female (White)
RS-232 1 x DB-9 Female (Black)
Power 2 x DC Jack (Black)
LAN Ports 1 x RJ-45 (Black)
1 x SFP Slot
Internet Port 1 x RJ-45 (Black)
USB Port 1 x USB Type-A Female (White)
Control 1 x 6-Pin Mini-DIN (Purple)
I/O 9 x DI (0 - 24V) (Front)
1 x DO (0 - 24V) (Rear)
Relay 8 x Relay (Max 24VDC, 1.2A) (Rear)
Switches OSD N/A
Video N/A
Graphics N/A
Mode Selection 1 x Slide Switch (Auto, RS-232 Config/Access
Control, Local)
Reset 2 x Semi-recessed Pushbutton
LEDs Power 2 x Green
Local 1 x Green
Remote 1 x Green
10 / 100 / 1000 Mbps 2 x LAN (100: Orange / 1000: Green)
Link 2 x LAN (Green)
1 x SFP (Green)
Emulation Keyboard / Mouse USB
