RCM KVM over IP Transmitter User Manual
50
Access Management
Local Console Access
Remote Port Access
Checking Access Control Box Pushbutton
Function Description Example
DisableLocalConsole(
<SID>)
Disables local console access.
DisableLocalConsole(
4)
EnableLocalConsole(
<SID>)
Enables local console access.
EnableLocalConsole(
4)
Function Description Example
LockClientLogin(<SID
>)
Prohibits remote access to the remote
port.
Returned value of ‘0’ = Success
LockClientLogin(4)
UnlockClientLogin(<S
ID>)
Allows remote access to the remote
port.
Returned value of ‘0’ = Success
UnlockClientLogin(4)
SetPortAccessMode(
1,<access mode>)
Sets the access mode for the remote
port.
0 = full access
1 = view only
2 = denied access
SetPortAccessMode(
1,0)
Function Description Example
GetLocalPushButtonS
tatus(<SID>)
Shall be used in conjunction with the
ATEN Access Control Box, checks the
current pushbutton status.
0 = released
1 = pressed
GetLocalPushButtonS
tatus(4)
