Aten RCMDVI40BT [73/297] Osd interface

Chapter 4. OSD Operation

Microphone Hotkey

You can switch microphone access between receivers with a hotkey:

1. Press and hold down [Num Lock].

2. Press and release [-].

3. Release [Num Lock].

4. Press 1.

Press the Esc key to cancel.

OSD Interface

After you invoke the OSD, the main page appears:

Note: A password is required to enter the OSD. The default password is:

password. For security purposes, the system will prompt you to change

the password.

The OSD components are described in the table below:

No. Item Description

1 Receiver Select this radio button, enter a password, and click

Configure to enter the Receiver Configuration screen.
