RCM KVM over IP Transmitter User Manual
156
Heading Item Description
Basic RCM/KE Manager
Version
This provides the version of the RCM/KE Manager
software.
Serial Number This provides the serial number and a link to
upgrade the software.
RCM/KE Manager
Name
Enter a name for the RCM/KE Manager.
Description Enter a description for the RCM/KE Manager.
Language Select the language for the RCM/KE Manager.
Choices are: English, Chinese (Traditional),
Simplified Chinese, Japanese, German, Korean,
Russian, French, Spanish, and Portuguese.
Beeper Select Enable to sound a beep from the
transmitter / receiver every time a configuration
change is made.
CCKM Timeout If there is no user input for the amount of time
entered in the box, a user logged into the CCKM
is automatically logged out. Check Disable to turn
this function off.
Authentication Lock When accidental power cut happens, the function
allows the user to retain his/her settings as was
shown before the power cut. The user keeps the
same authentication and display.
Uncheck Disable to turn this function on.
Specify a time (in seconds) you wish to keep
the authentication and display for.
When disabled or, if enabled, after the time
specified above, the manager will prompt you to
authenticate when you wish to access the KE
Manager.
Boundless Switching
Focus
When using Boundless Switching(see Boundless
Switching, page 135) across multiple receivers
within a receiver group or video wall, a colored
border is shown on the receiver display currently
being accessed (focus receiver).
Uncheck Always to only display the colored
border for a set time interval immediately after
switching the focus receiver.
Specify a time (in seconds) you wish to display
the colored border for upon switching the focus
receiver.
Push / Pull Login
Check
Enable to check the access rights of the users
receiving transmitter sessions upon push / pull.
