RCM KVM over IP Transmitter User Manual
192
2. Provide a valid Username and Password and click OK to continue.
Note: The default Username is administrator and the default Password is
password.
After you have successfully logged in, the connection screen reappears:
At this time there are two active buttons and are described in the table
below:
3. Click Switch to remote view to access the video source(s)’ display(s).
Refer to The Control Panel on page 193 for information about the remote
access interface.
Button Action
Disconnect Breaks the connection to the unit.
Switch to remote
view
Opens a window on the user’s desktop containing the remote
server’s display that is the same as the one that appears with the
browser-based Windows client.
