RCM KVM over IP Transmitter User Manual
236
read o i xx rs232 Read output or input xx
RS-232 properties
xx: Device ID or IP
address
read o i xx properties Read output or input xx
connection properties
xx: Device ID or IP
address
read o i xx manager Read output or input xx
KVM over IP Matrix
Manager IP and port
properties
xx: Device ID or IP
address
read o i xx streams Read output or input xx
enable media
properties
xx: Device ID or IP
address
read o xx tx Read output xx source
stream IP address
properties
xx: receiver ID or IP
address
read o xx usbmode Read output xx USB
mode properties
xx: receiver ID or IP
address
read i xx multicast Read input xx multicast
properties
xx: transmitter ID or IP
address
read i xx videoqtyad
vanced
Read input xx
advanced video
properties
xx: transmitter ID or IP
address
read i xx ossettings Read input xx OS
properties
xx: transmitter ID or IP
address
read all Read all properties of
local receiver
Comman
d
Output Input Number Control Description
