Chapter 14. CLI Commands
239
Control Description
Name Sets the device name
Description Sets the device description
ipInstallerFlag Sets the IP installer option
dhcpFlag Sets the DHCP setting
ipAddr Sets the IP address
netmask Sets the subnet mask
gw Sets the default gateway
modeFlag Sets the device mode
BaudRate Sets the baud rate setting
Parity Sets the parity setting
DataBit Sets the data bit setting
StopBit Sets the stop bit setting
FlowCtrl Sets the flow control setting
TxVideoIP Sets the transmitter video IP setting
TxAudioIP Sets the transmitter audio IP setting
TxUSBIP Sets the transmitter USB IP setting
TxRSIP Sets the transmitter RS-232 IP setting
VideoEnFlag Sets the (enable media) video source
stream
AudioEnFlag Sets the (enable media) audio source
stream
USBEnFlag Sets the (enable media) USB source
stream
RSEnFlag Sets the (enable media) RS232
source stream
ManagerIP Sets the KVM over IP Matrix Manager
IP
ManagerPort Sets the KVM over IP Matrix Manager
port
Beeper Sets the beeper
RxVM Sets the USB mode setting
USBSecure Sets the USB encryption
PortOS Sets the port OS setting
OSLanguage Sets the OS language
videoMCastEn Sets the enable multicast video setting
