Chapter 14. CLI Commands
245
Set i xx ColorDepth yy Set input xx ColorDepth
to yy
xx: Device ID or IP
address
yy: 8, 16, 24
Set i xx BandwidthLimit yy Set input xx
BandwidthLimit to yy
xx: Device ID or IP
address
yy: unlimited, 100, 200,
500
Set i xx VideoQty yy Set input xx VideoQty
to yy
xx: Device ID or IP
address
yy: 1, 2, 3, 4, 5
Set i xx BGRefresh yy Set input xx BGRefresh
to yy
xx: Device ID or IP
address
yy: off, 16, 32, 64, 128,
256
Set i xx OccupyTimeout yy Set input xx
OccupyTimeout to yy
xx: Device ID or IP
address
yy: 1~240
Set i xx Resolution yy Set input xx Resolution
to yy
xx: Device ID or IP
address
yy: 1920x1200,
1920x1080,
1680x1050,
1600x1200, 1600x900,
1440x900, 1400x1050,
1366x768, 1280x1024,
1280x960, 1280x720,
1152x864, 1024x768,
800x600, 720x400,
640x480
Comm
and
Output Input Number Control Value Description
