RCM KVM over IP Transmitter User Manual
80
2 Description The field provides a description of the receiver that
was entered when it was created.
3 Connect Click Push Content to push the local receiver’s
channel connection to the selected receiver’s
console. The local receiver’s channel connection will
appear on the receiver that it was pushed to and
both will share access to the computer. The access
mode selected at the local receiver will determine
how access is shared (see Transmitter Permissions,
page 127 for details).
5 Next Arrow Use these two buttons to navigate to the next page
or to the end of the list if there are more choices
available than can be seen on the page.
6 Previous Arrow Use these two buttons to navigate to the previous
page or to the beginning of the list if there are more
choices available than can be seen on the page.
9 Logout Click this button to log out of the Connection Page.
10 Go to Configuration
Window
Click this button to return to the main OSD screen.
No. Item Description
