Yamaha FZR1000 (1993) [23/74] Crankcase cover 1
![Yamaha FZR1000 (1993) [23/74] Crankcase cover 1](/views2/1121431/page23/bg17.png)
27 4BH-15461-00-00 GASKET, CRANKCASE
COVER 2 . . . . . . . . . . . . . . . . . 1
28 99510-08012-00 PIN, DOWEL . . . . . . . . . . . . . . 2
29 95023-06030-00 BOLT, FLANGE (95021-06030) . 2
30 95023-06020-00 BOLT, FLANGE . . . . . . . . . . . . 9
CRANKCASE COVER 1
Ref. Part
No. Number Description Qty Remarks
B11
FZR1000E_EC
