Konica Minolta bizhub PRO C500 [179/466] Colour copy quality
![Konica Minolta bizhub PRO C500 [179/466] Colour copy quality](/views2/1122251/page179/bgb3.png)
7-9
Colour Copy Quality
The hue adjustment leads the colour of the image to another colour adjacent
in the colour circle of red (R), yellow (Y), green (G), cyan (C), blue (B), and
magenta (M).
+4–4
Brightness
