Lay Out Several Pages onto One Sheet (Combination)
10-14
Original Type and Layout Order
Refer to the table below to select the desired Combination mode.
2 in 1 4 in 1 8 in 1 4 in 1 8 in 1
Horizontal order Vertical order
Landscape type
Portrait type
Original
Layout
