Caution Labels and Indicators
1-14
CAUTION
ATTENTION
PRECAUCION
CUIDADO
CAUTION
ATTENTION
VORSICHT
PRECAUCION
ATTENZIONE
注意
CAUTION
CAUTION
CAUTION
Inside the lower paper
exit outlet is the roller
drive unit. DO NOT put
your hand into it;
otherwise you may be
injured.
Use care after opening the
paper exit outlet. DO NOT put
your hand into it; otherwise
you may be injured.
(Finisher with PI-110
Cover Sheet Feeder only)
To avoid injury, DO NOT
put your hand on top of
the printed sheets.
Be sure to hold both sides
of the printed sheets when
removing them, and DO
NOT leave your hand on
the printed sheets while
the primary (main) tray
goes up.
DO NOT insert your
finger into the bottom
of the upper part of the
feeder when returning
to its original position;
otherwise you may be
injured.
