8-9
Making Folded Booklet (Fold / Stitch & Fold)
Making Folded Booklet (Fold / Stitch & Fold)
The Fold and Stitch & Fold modes are available only when the FS-606 Finisher
option is installed. When any of these modes is selected, the Booklet feature is
automatically selected and indicated on the Application Selection Screen.
• When copying two-sided signature originals using the Fold or Stitch &
Fold mode, release the automatically selected Booklet mode on the
Application Selection Screen.
• When copying dark originals or using Reverse Image mode together with
Fold or Stitch & Fold mode, the folded line of the output copies may be
slightly shifted.
The following copy results may be expected when using Fold or Stitch & Fold mode:
In the Fold mode, each copied set is folded and output to the Booklet tray of the
finisher.
In the Stitch & Fold mode, each copied set is stapled at two positions (saddle
stitched), then folded and output to the Booklet tray of the finisher.
Specifications for Fold / Stitch & Fold Mode
/ Use RADF.
/ Max. number of folded sheets in Fold mode
105 g/m
2
paper or less: 3 sheets
(less than in Stitch & Fold mode because they are not clinched first)
/ Max. number of folded sheets in Stitch & Fold mode
80 g/m
2
paper: 20 sheets
19 sheets with a thick cover paper
105 g/m
2
paper: 16 sheets
15 sheets with a thick cover paper
/ Paper size: A3, B4, A4R, 11”x17”, 8.5”x14”, 8.5”x11”R
/ Paper weight: 64 ~ 105 g/m
2
(80 g/m
2
paper is recommended)
/ Booklet tray capacity:
When the Booklet tray capacity is exceeded, the finisher will stop operating.
Select the appropriate print quantity by referring to the following capacities.
Approx. 100 sheets max. (A3, B4, 11”x17”, 8.5”x14” / 80 g/m
2
paper)
Fold:
33 sets max. of 3-sheet-folded booklet (33 x 3 = 99 sheets)
Stitch & Fold:
20 sets max. of 5-sheet-folded booklet (20 x 5 = 100 sheets)
5 sets max. of 20-sheet-folded booklet (5 x 20 = 100 sheets)
Approx. 75 sheets max. (A4R, 8.5”x11”R / 80 g/m
2
paper)
Fold:
25 sets max. of 3-sheet-folded booklet (25 x 3 = 75 sheets)
Stitch & Fold:
15 sets max. of 5-sheet-folded booklet (15 x 5 = 75 sheets)
/ Incompatible conditions with Booklet selected: APS, 1)1, 2)1, ACS, Sort,
Staple-sort, Group, Face Up, Three-Fold, Rotation Sort, Rotation Group,
Punch, Back cover feeding, Mixed Original, Full Area in Non STD size, Tab
Paper, Sheet/Cover Insertion, Combination, Program Job, Multi-Page
Enlargement, Non-Image Area Erase, Reverse Image, Repeat
/ Incompatible conditions without Booklet: Sort, Staple-sort, Group, Face Up,
Rotation Sort, Rotation Group, Three-Fold, Punch, Back cover feeding,
Mixed Original, Dual Page, Program Job, Multi-Page Enlargement, Reverse
