1-13
Caution Labels and Indicators
DO NOT throw the toner
recovery box into a fire. If it
is thrown into a fire, the
toner may ignite and cause
a dangerous situation.
To avoid any unexpected
injury, DO NOT put your hand
into the holes (3 places) on
the bottom plate of the LCT.
DO NOT INSERT
your finger into
the two RADF
hinge portions;
otherwise you
may be injured.
(Rear side of the RADF)
(Inside of the LCT)
(Right rear side
of the Main body)
CAUTION
WARNING
CAUTION
