Rotation
8-4
Rotation
This function allows you to utilize APS or AMS and copy the original documents
onto size A4 or B5, irrespective of the copy paper feeding direction.
By default, Rotation requires APS or AMS to function. The Key Operator can
set this function ON, or to operate when APS, AMS or reduce functions. See
p. 14-38.
The copier is initially set to activate the Rotation function automatically.
Follow the procedure below to release/resume this function.
Copy Original Copy Original
Normal copying
Rotation copying
Normal copying
Rotation copying
