Konica Minolta bizhub PRO C500 [373/466] Maintenance supplies
![Konica Minolta bizhub PRO C500 [373/466] Maintenance supplies](/views2/1122251/page373/bg175.png)
13
Maintenance & Supplies
How to Maintain the Copier
Adding Toner......................................................................................13-2
Inserting a New Staple Cartridge into FS-513/FS-606 Finisher ........13-7
Empty Waste Basket of PK-507/PK-508 Punching Kit....................13-11
Empty Waste Basket of TU-109 Trimmer Unit .................................13-13
Exchanging Toner Recovery Box.....................................................13-15
Cleaning Image Scanning Section...................................................13-17
Checking Copy Count......................................................................13-21
Periodic Maintenance ......................................................................13-24
