8-11
Making Folded Booklet (Fold / Stitch & Fold)
Selecting FOLD or STITCH & FOLD will automatically switch the output tray
to Booklet tray. Notice that the arrow pointing from the Main tray shifts to the
Booklet tray.
When selecting STITCH & FOLD, the machine with the trimmer unit installed
selects TRIM automatically. To cancel the trimming mode, touch TRIM to
deselect it.
4. Touch OK on the Output Mode popup menu.
The Basic Screen will be restored and the selection made in the output mode
will be reflected in the OUTPUT icon area.
5. Select additional copying features, as required.
NO COVER SHEET of Booklet is automatically selected.
To change this selection, touch APPLICATION on the Basic Screen to
display the Application Selection Screen, then touch Booklet twice to display
the Booklet Mode Selection Screen to make another selection or to release
the setting.
6. Enter the desired print quantity from the control panel keypad.
See p. 3-10 for details on setting print quantity.
7. Position originals.
See p. 3-4 for details on positioning originals.
When loading originals, heed the following limits on capacity:
Fold mode:
12 pages or less for simplex copying
6 pages or less for duplex copying
Stitch & Fold mode:
80 pages or less for simplex copying (80 g/m
2
paper only)
40 pages or less for duplex copying (80 g/m
2
paper only)
Exceeding the above capacity limits may cause trouble in the finisher.
8. Press [START].
When the Booklet tray capacity is exceeded, the finisher will cease
operating. To avoid this, select the appropriate print quantity from
the specifications shown on p. 8-9.
