2-5
Machine Configuration
Standard/Optional Equipment
PK-507/PK-508 Punching kit
PI-110 Cover sheet feeder
CV-131 Platen cover
DF-319 Document feeder
Work table
Key counter
LT-211 Large
bizhub PRO C500
FS-513 Finisher
MU-412 Memory unit
HD-106 Hard disk drive
IP-901Printer controller
FS-606 Finisher
TU-109A kit
TU-109 Trimmer unit
capacity tray
(Fiery S300 50C-K)
main body
