Paper Information
12-4
• See p. 14-22 for Paper Type setting of Tray 1, 2, 3 or LCT.
• See p. 3-20 for Paper Type setting of Multi-sheet bypass tray.
When paper type of 106 g/m
2
to 256 g/m
2
is specified, copy speed may
become one-second to one-third lower. For more detailed information,
contact your service representative.
