An Outline of the Key Operator Mode
14-4
5. Touch PREVIOUS SCREEN to exit the Key Operator Mode.
The Basic Screen will be restored.
[24] can be registered and recalled as a profile. Contact your service
representative, if desired. See p. 8-26 for details.
Printer Lead Edge Timing Adjustment (Side 1 / Side 2), Printer Registration
Loop Adjustment (Side 1 / Side 2), Printer Centring Adjustment (Side 1 / Side
2), Printer Vertical Magnification Adjustment (Side 1 / Side 2*), Printer
Horizontal Magnification Adjustment (Side 1 / Side 2)
*: Available only when Memory Switch No. 42 is turned ON.
