Repeating Selected Image Area (Repeat: Vert./Horiz. Mode)
10-40
7. Enter the desired print quantity from the control panel keypad.
See p. 3-10 for details on setting print quantity.
8. Position original FACE DOWN on the platen glass.
See the illustration on p. 10-38 for details.
9. Press [START].
When the finisher / trimmer unit / paper exit tray capacity is
exceeded due to the print quantity selected, remove the copied sets
as they exit; otherwise, mishandled paper will occur.
